Leírás
Specifikáció: ATX 12V 2.3Hatékonyság:
>85%Méret (MéxSzéxMa):
140 mm x 150 mm x 86 mmPFC:
Active PFC (0,9)Fan:
120mm halk
Biztonság:UVP (Undervoltage protection)OVP (Overvoltage protection)SCP (Short-circuit protection)OPP (Overload protection)AFC (Automatic Fanspeed Control)
AC Input:
230V / 6,3AFrequency:
50 Hz+5V:
22A+3,3V:
22A+5V & +3,3V combined:
120W+12V 1:
45A / 540W+12V 2:
N/A+12V 1 & +12V 2 combined:
N/A+12V 3:
N/A+12V 4:
N/A+12V 3 & +12V 4 combined:
N/AP.F.:
>0,9-12V:
0,3A / 3,6W+5VSB:
2,5A / 12,5WMaximum Load:
600W
24PIN:===400mm===[24PIN]SATA / Molex:===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===[Molex]SATA / Molex:===350mm===[SATA]===150mm===[SATA]===150mm===[SATA]===150mm===Molex]6+2 PCIe:===450mm===[6+2 PCIe]===150mm===[PCIe]8PIN EPS (4+4):===500mm===[8PIN EPS]
Paraméterek
| Teljesítmény (W) | 600 |
